Unequal Angles - L Sections - Structural Steel Angles

BS EN 10025-2 : 2004 - S275JR / S355JR

A mild steel unequal angle, also known as an L section, is a structural steel profile with two legs of differing lengths forming an L-shape, commonly used for support and framing in construction and engineering applications.

Known for their exceptional strength and durability, mild steel unequal angles are suitable for both short-term and long-term loading conditions.

These angles are often used in construction and engineering applications due to their versatility.

We stock a large range of Unequal Angles available for immediate off-the-shelf delivery using our own reliable and efficient nationwide transport fleet.

Barrett Steel supplies a huge range of structural steel to the construction industry and DIY market across the entire UK.

Unequal Angles - L Sections - Structural Steel Angles
VIEW OUR
QUALITY CERTS

Steel Unequal Angle Sizes & Weights

Size (mm) Kg/m
40 x 25 x 4 1.93
40 x 25 x 5 2.37
60 x 30 x 5 3.37
65 x 50 x 5 4.35
65 x 50 x 6 5.16
65 x 50 x 8 6.75
75 x 50 x 6 5.65
75 x 50 x 8 7.39
80 x 60 x 6 6.37
80 x 60 x 8 8.34
100 x 50 x 6 6.85
100 x 65 x 7 8.77
100 x 65 x 8 9.94
100 x 65 x 10 12.3
100 x 75 x 8 10.6
100 x 75 x 10 13.0
100 x 75 x 12 15.4
125 x 75 x 8 12.2
125 x 75 x 10 15.0
125 x 75 x 12 17.8
150 x 75 x 10 17.0
150 x 75 x 12 20.2
150 x 75 x 15 24.8
150 x 90 x 10 18.2
150 x 90 x 12 21.6
150 x 90 x 15 26.6
200 x 100 x 10 23.0
200 x 100 x 12 27.3
200 x 100 x 15 33.7
200 x 150 x 12 32.0
200 x 150 x 15 39.6
200 x 150 x 18 47.1
